Technical parameter：
1.Magnification: 5-step magnification changer 0.4X,0.6X,1.0X,1.6X,2.5X.
2.Binoculars: 45°inclined binocular f'=170mm
Straight binocular f'=170mm
0-180°inclinable binocular f'=170mm
3.Eyepiece: 12.5X,widefiled and adjustable eyecup
10X/16X/20X for options
4.Total magnification and visual field:
f'=250mm,12.5X eyepiece,45°binocular | ||||
3.4X | 5.4X | 8.5X | 13.5X | 21.2X |
65mm | 42mm | 26mm | 16mm | 10mm |
5.Focus:
Manual,with rang of 12mm |
5 objective lenses available |
f'=200mm (with fine focus,option) |
f'=250mm (with fine focus) |
f'=300mm/350mm/400mm(option) |
Detailed Photos.
Technical parameter：
1.Magnification: 5-step magnification changer 0.4X,0.6X,1.0X,1.6X,2.5X.
2.Binoculars: 45°inclined binocular f'=170mm
Straight binocular f'=170mm
0-180°inclinable binocular f'=170mm
3.Eyepiece: 12.5X,widefiled and adjustable eyecup
10X/16X/20X for options
4.Total magnification and visual field:
f'=250mm,12.5X eyepiece,45°binocular | ||||
3.4X | 5.4X | 8.5X | 13.5X | 21.2X |
65mm | 42mm | 26mm | 16mm | 10mm |
5.Focus:
Manual,with rang of 12mm |
5 objective lenses available |
f'=200mm (with fine focus,option) |
f'=250mm (with fine focus) |
f'=300mm/350mm/400mm(option) |
6.Illumination:
Coaxial illumination by optical light-guide system |
*Halogen:15V/150W,two bulbs,continuously |
Light-intensity adjustment,50000Lux (f'=250mm) |
*LED:50W,over 50000 hours life time |
90000Lux (f'=250mm) |
75000Lux (f'=300mm) |
*filed of view:50mm (f'=300mm) |
7.Filter: Green/yellow for Dental,or green/blue for ENT
8.Stand type and Gross weight:
Floor stand 125kg |
Wall mount 80kg |
Ceiling mount 95kg |
9.Accessories:
Beam splitter 50/50 or 20/80 |
Adaptor for 1/3 video camera |
Integrated beam splitter and adaptor |
Video system:built-in 1/2 inch CCD camera with 540TVL |
Or HDMI 1920*1080P,1/3 inch HD CMOS sensor |
